TUNE IN TO VICTORY
Class leading performance and suspension along with the smartphone power tuner app make this the bike of choice for race winners.
GALLERY
360° VIEW
0%
HOTSPOT
TYRE
ENGINE
EXHAUST
TYRE
CLUTCH
SPECIFICATIONS
Engine Type
450cc liquid-cooled DOHC 4-stroke; 4 titanium valves
Bore x Stroke
97.0mm × 60.8mm
Compression Ratio
13.0:1
Fuel Delivery
Mikuni® fuel injection, 44mm
Transmission
5-speed; multiplate wet clutch
Final Drive
Chain
Suspension / Front
KYB® spring-type fork with speed sensitive damping; fully adjustable, 12.2-in travel
Suspension / Rear
KYB® single shock; fully adjustable, 12.5-in travel
Brakes / Front
Hydraulic disc, 270mm
Brakes / Rear
Hydraulic disc, 240mm
Tires / Front
80/100-21 Dunlop® MX33®
Tires / Rear
120/80-19 Dunlop® MX33®
L x W x H
86.0 in x 32.5 in x 50.6 in
Seat Height
38.0 in
Wheelbase
58.3 in
Rake (Caster Angle)
26.9°
Trail
4.7 in
Maximum Ground Clearance
13.0 in
Fuel Capacity
1.6 gal
Wet Weight
245 lb
INTRODUCING
THE ALL-NEW YAMAHA MOTOCROSS
Yamaha has a rich heritage of building the most sought after super sport motorcycles designed to deliver the pinnacle of performance on and off the track.
